TLP2304(TPR,E
TLP2304(TPR,E
- In Stock: 0
- Manufacturer: Toshiba Semiconductor and Storage
- Part Number: TLP2304(TPR,E
- Detailed Description: PHOTOCOUPLER HIGH SPEED 5PIN
- Category: 隔离器 | 光隔离器 - 逻辑输出光隔离器
- RoHS Status： 符合 RoHS 规范
- Datasheet: Datasheet
Reference Price (USD)
1+
$1.6920
10+
$1.5905
100+
$1.5059
1000+
$1.4213
10000+
$1.3367
Considering price fluctuations, this price is only for reference. Please send RFQ to sales@cytechsystems.com to get the best price, thank you.
Product Specifications
| Manufacturer | Toshiba Semiconductor and Storage |
|---|---|
| 系列 | - |
| 包装 | 卷带（TR） | 剪切带（CT） |
| 标准包装 | 3000 |
| 产品状态 | 在售 |
| 通道数 | 1 |
| 输入 - 侧 1/侧 2 | 1/0 |
| 电压 - 隔离 | 3750Vrms |
| 共模瞬变抗扰度（最小值） | 20kV/µs |
| 输入类型 | DC |
| 输出类型 | 开路集电极 |
| 电流 - 输出/通道 | 15 mA |
| 数据速率 | 1MBd |
| 传播延迟 tpLH / tpHL（最大值） | 550ns，400ns |
| 上升/下降时间（典型值） | - |
| 电压 - 正向 (Vf)（典型值） | 1.55V |
| 电流 - DC 正向 (If)（最大值） | 25mA |
| 电压 - 供电 | 4.5V ~ 30V |
| 工作温度 | -40°C ~ 125°C |
| 安装类型 | 表面贴装型 |
| 封装/外壳 | 6-SOIC（0.179，4.55mm 宽），5 引线 |
| 供应商器件封装 | 6-SO，5 引线 |
| 基本产品编号 | TLP2304 |
Environmental & Export
| RoHS Status | 符合 RoHS 规范 |
|---|---|
| Moisture Sensitivity Level (MSL) | 1（无限） |
| REACH Status | |
| ECCN | EAR99 |
| HTSUS | 8541.49.8000 |
