5746613-2
5746613-2
- In Stock: 0
- Manufacturer: TE Connectivity AMP Connectors
- Part Number: 5746613-2
- Detailed Description: CONN DIP HDR IDC 14POS VERT
- Category: 连接器，互连器件 | 矩形连接器 - 一件式线到板，直接线对板
- RoHS Status： 符合 ROHS3 规范
Reference Price (USD)
1+
$5.9280
10+
$5.5723
100+
$5.2759
1000+
$4.9795
10000+
$4.6831
Considering price fluctuations, this price is only for reference. Please send RFQ to sales@cytechsystems.com to get the best price, thank you.
Product Specifications
| Manufacturer | TE Connectivity AMP Connectors |
|---|---|
| 系列 | AMP-Latch |
| 包装 | 托盘 |
| 标准包装 | 180 |
| 产品状态 | 在售 |
| 连接器类型 | 带状电缆，DIP 针座 |
| 针位数 | 14 |
| 电缆间距 | 0.050"（1.27mm） |
| 板侧间距 | 0.100"（2.54mm） |
| 排数 | 2 |
| 排距 | 0.300"（7.62mm） |
| 安装类型 | 通孔 |
| 电缆端接 | IDC |
| 线规 | 28 AWG，绞合；26-30 AWG，实心 |
| 特性 | 馈通式 |
| 触头表面处理 | 镀金 |
| 触头表面处理厚度 | 5.00µin（0.127µm） |
| 颜色 | 黑色 |
| 加载的针位数 | 所有 |
| 基本产品编号 | 5746613 |
Environmental & Export
| RoHS Status | 符合 ROHS3 规范 |
|---|---|
| Moisture Sensitivity Level (MSL) | 1（无限） |
| REACH Status | 非 REACH 产品 |
| ECCN | EAR99 |
| HTSUS | 8536.69.4040 |
