BXRC-50C2000-C-Z4

BXRC-50C2000-C-Z4

BXRC-50C2000-C-Z4

  • In Stock: 0
  • Manufacturer: Bridgelux
  • Part Number: BXRC-50C2000-C-Z4
  • Detailed Description: LED ARRAY 2000LM COOL WHITE
  • Category: 光电器件 | COB,引擎,模块,灯条
  • RoHS Status:

Product Specifications

Manufacturer Bridgelux
系列 Vero® 13 Array
包装 托盘
标准包装 20
产品状态 停产
类型 板上芯片(COB)
颜色 白色,冷色
CCT (K) 5000K 4 阶麦克亚当椭圆
波长 -
配置 圆形
不同电流/温度下的光通量 2037lm(标准)
电流 - 测试 500mA
温度 - 测试 85°C
电压 - 正向 (Vf)(典型值) 31.3V
流明/瓦,不同电流 - 测试时 130 lm/W
电流 - 最大值 1.05A
CRI(显色指数) 70
视角 120°
特性 带连接器
大小 / 尺寸 36.20mm 直径
高度 1.90mm
发光面 (LES) 13.20mm 直径
透镜类型 扁平
基本产品编号 BXRC-50

Environmental & Export

RoHS Status
Moisture Sensitivity Level (MSL) 1(无限)
REACH Status
ECCN EAR99
HTSUS 8539.52.0091
