CLF12555T-1R5N-CA
CLF12555T-1R5N-CA
- In Stock: 0
- Manufacturer: TDK Corporation
- Part Number: CLF12555T-1R5N-CA
- Detailed Description: FIXED IND 1.5UH 6.7A 9.5MOHM SMD
- Category: 电感器，线圈，扼流圈 | 固定电感器
- RoHS Status：
- Datasheet: Datasheet
Reference Price (USD)
1+
$0.0000
10+
$0.0000
100+
$0.0000
1000+
$0.0000
10000+
$0.0000
Considering price fluctuations, this price is only for reference. Please send RFQ to sales@cytechsystems.com to get the best price, thank you.
Product Specifications
| Manufacturer | TDK Corporation |
|---|---|
| 系列 | CLF-CA |
| 包装 | 卷带（TR） | 剪切带（CT） |
| 标准包装 | 500 |
| 产品状态 | 停产 |
| 类型 | 鼓芯，绕线式 |
| 材料 - 磁芯 | 铁氧体 |
| 电感 | 1.5 µH |
| 容差 | ±30% |
| 额定电流（安培） | 6.7 A |
| 电流 - 饱和 （Isat） | 16.4A |
| 屏蔽 | 屏蔽 |
| DC 电阻 (DCR) | 9.5 毫欧最大 |
| 不同频率时 Q 值 | - |
| 频率 - 自谐振 | - |
| 等级 | AEC-Q200 |
| 工作温度 | -40°C ~ 105°C |
| 电感频率 - 测试 | 100 kHz |
| 安装类型 | 表面贴装型 |
| 封装/外壳 | 非标准 |
| 供应商器件封装 | - |
| 大小 / 尺寸 | 0.492 长 x 0.476 宽（12.50mm x 12.10mm） |
| 高度 - 安装（最大值） | 0.230（5.85mm） |
Environmental & Export
| RoHS Status | |
|---|---|
| Moisture Sensitivity Level (MSL) | 1（无限） |
| REACH Status | 非 REACH 产品 |
| ECCN | EAR99 |
| HTSUS | 8504.50.4000 |
