NCP5109BDR2G
NCP5109BDR2G
- Available: 1000
- Manufacturer: onsemi
- Part Number: NCP5109BDR2G
- Detailed Description: IC GATE DRVR HALF-BRIDGE 8SOIC
- Category: 集成电路（IC） | 电源管理（PMIC） - 栅极驱动器
- RoHS Status： 符合 ROHS3 规范
- Datasheet: Datasheet
Reference Price (USD)
1+
$1.4880
10+
$1.3987
100+
$1.3243
1000+
$1.2499
10000+
$1.1755
Considering price fluctuations, this price is only for reference. Please send RFQ to sales@cytechsystems.com to get the best price, thank you.
Product Specifications
| Manufacturer | onsemi |
|---|---|
| 系列 | - |
| 包装 | - |
| 标准包装 | 2500 |
| 产品状态 | 在售 |
| 驱动配置 | 半桥 |
| 通道类型 | 独立式 |
| 驱动器数 | 2 |
| 栅极类型 | IGBT，N 沟道 MOSFET |
| 电压 - 供电 | 10V ~ 20V |
| 逻辑电压 - VIL，VIH | 0.8V，2.3V |
| 电流 - 峰值输出（灌入，拉出） | 250mA，500mA |
| 输入类型 | 非反相 |
| 高压侧电压 - 最大值（自举） | 200 V |
| 上升/下降时间（典型值） | 85ns，35ns |
| 工作温度 | -40°C ~ 125°C（TJ） |
| 安装类型 | 表面贴装型 |
| 封装/外壳 | 8-SOIC（0.154"，3.90mm 宽） |
| 供应商器件封装 | 8-SOIC |
| 基本产品编号 | NCP5109 |
Environmental & Export
| RoHS Status | 符合 ROHS3 规范 |
|---|---|
| Moisture Sensitivity Level (MSL) | 1（无限） |
| REACH Status | 非 REACH 产品 |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
